MODEL | FL110 | FL130 | FL150 | FL170 |
Dimensions(mm) | 1300x710x720 | 1500x710x720 | 1700x710x720 | 1900x710x720 |
Structure Weight (kg) | 165 | 180 | 200 | 220 |
Cutting width (cm) | 106 | 126 | 146 | 166 |
Cutting height (mm) | 0-60mm | 0-60mm | 0-60mm | 0-60mm |
Rotor diameter (mm) | 76 | 76 | 76 | 76 |
Hammer Number | 20 | 24 | 28 | 32 |
PTO Turing speed(rpm) | 540 | 540 | 540 | 540 |
PTO shaft size(mm) | T4-800 | T4-800 | T4-800 | T4-800 |
Power Required (hp) | 20-30 | 25-35 | 30-40 | 30-40 |
Packing Size (cm) | 1300x720x570 | 1500x720x570 | 1700x720x570 | 1900x720x570 |
