Flail Mower DP-A
Flail Mower DP-A
The DP-A is a new design of PTO mounted agricultural equipment that is specifically used to handle heavier grass and scrub which cannot be managed by a regular lawn mower.
E-mail: johnson@aiemery.com
Specification of Flail Mower DP-A
MODEL | DP-A135 | DP-A155 | DP-A175 | DP-A195 | DP-A205 |
Dimensions(mm) | 1505×950×910 | 1705×950×910 | 1905×950×910 | 1905×950×910 | 1905×950×910 |
Structure Weight (kg) | 314 | 343 | 372 | 395 | 418 |
Cutting width (cm) | 135 | 155 | 175 | 195 | 205 |
Cutting height (mm) | 0-60mm | 0-60mm | 0-60mm | 0-60mm | 0-60mm |
Rotor diameter (mm) | 108 | 108 | 108 | 108 | 108 |
Belt No. | 3 | 4 | 4 | 4 | 4 |
Hammer Number | 24 | 24 | 28 | 32 | 32 |
Y blade | 48 | 48 | 56 | 64 | 64 |
Side shift distance | 348 | 348 | 348 | 348 | 348 |
Power Required (hp) | 20-30 | 30-40 | 40-50 | 40-50 | 40-50 |
