Idea for cleaning green areas, gardens, slopes, ditches, bank of watercourses, road side banks.
Suited for tractors from 40 to 130HP.
Uses:
- The Verge Flail Mowers are flail mowers with hydraulic am for cleaning larger, wider areas, roadsides verges, orchards and various inclining and declining land surfaces;
- Specially designed for universal use the head of the mower can be operate in line with the tractor or offset for verge maintenance and field boundaries.
Feature:
- The Verge Flail Mowers are suitable for roadside verge, tree trimming and general mulching;
- Hydraulic side adjustment;
- Hydraulic inclining adjustment;
- Rear roller wheel;
- High power 50hp gearbox;
- Self leveling;
- High strength mulching blades;
- Safety flaps;
- Extra strong and designed with safety in mind;
- Support legs for storage;
- Solid hitch.
The heavy verge Flail Mowers are flail mowers with hydraulic arm for clearing larger, wider areas, roadsides verges, orchards and vineyards.
1. Fitted with a high power 50hp gear box;
2.Cutting height controlled by adjustable skids;
3.High strength mulching blades
4. Hammer blade Standard Hammer Blade
5. Optional part: Hydraulic valve
Main Specification on AGH Flail Mower:
MODEL | AGH-140 | AGH-160 |
DIMENSIONS(L×W×H) | 1800×1850×1020mm | 1820×2050×1020mm |
STRUCTURE WEIGHT | 564Kg | 590Kg |
CUTTING WIDTH | 1.4m | 1.6m |
WORKING EFFICIENCY | 6000-16000m2/h | 6000-16000m2/h |
PTO TURNNING SPEED | 540r/min | 540r/min |
PTO SPLINE | 6×8×1600mm | 6×8×1600mm |
POWER REQUIRED | 40-85HP | 50-90HP |
MODEL | AGH-180 | AGH-200 |
DIMENSIONS(L×W×H) | 1800×2250×1020mm | 1820×2450×1020mm |
STRUCTURE WEIGHT | 618Kg | 648Kg |
CUTTING WIDTH | 1.8m | 2.0m |
WORKING EFFICIENCY | 6000-16000m2/h | 6000-16000m2/h |
PTO TURNNING SPEED | 540r/min | 540r/min |
PTO SPLINE | 6×8×1600mm | 6×8×1600mm |
POWER REQUIRED | 60-90HP | 65-100HP |
